COMPANY PROFILEGETABEC group (German-Thai Boiler Engineering Cooperation Ltd.), is one of the famous and leading boiler and pressure vessel manufacturer in Asia, founded in 1983.GETABEC can manufacture steam boiler, hot water boiler, waste heat boiler, thermal oil heater and pressure vessel complied to ASME, EN, CE, DIN, BS, PED, TRD, etc. Our work-shops have been qualified and received international certificates of ISO 9001:2008, HP-0/TRD 2001 by TUV NORD and S, U, R, PP as authorized manufacturer of ASME code for boiler and pressure vessel. GETABEC also manufaturers boiler under license of SCHNEIDER-KESSEL Berlin for fire-tube boiler, Eckroh Kessel (ERK) Berlin for water tube and waste heat boiler, VYNCKE Belgium for biomass boiler. GETABEC is a long time cooperated partner of SAACKE Burner, Bremen for Sales and service in Thailand. GETABEC has market their boiler and service world-wide and well accepted by many famouse international companies.
Products

Steam Boiler

Page 1

Page 2

GETABECKESSEL

Steam Boiler

GETABECKESSELGETABECKESSEL that we produce is a high-efficiency steam and hot water boiler for every application, in various designs with energy saving system and fully automatic operation without need to constant supervision. These boilers are three pass, wet-back design principle. The water contents can be quickly transformed into steam. Our boilers always have sufficient steam reserve, even during sudden peak demand period. Using a gas or oil or dual fuel burner, the frame intensity is matched virtually instantly to the steam or hot water consumption, taking into account the fuel characteristic. By the way, another positive factor is that a large flame tube effectively reduces the NOx emission. GETABECKESSEL can cope easily with peak and low-demand periods for steam or hot water. Output per boiler up to 30 ton/hr. Operating pressure up to 24 bar. GETABECKESSEL can produce saturated steam, low-pressure saturated steam, superheated steam and high pressure hot water as required by local heat, district heat and process heat, from the individual boiler to large boiler plant, boiler with feed water treatment, feed water storage and deaeration, with heat recovery assemblies, with noise suppression, with special components. Upon request, we can also show you operation reference installations. All parts of boiler from are sturdily built, with plenty of reserve performance. Only components internationally recognized brand named are used, with pressure controller and safety pressure limiter, equipped for fully automatic boiler operation. We trust in our service teams by our qualified engineers and technicians complete customers requirements as well as parts availability.

Biomass Boiler

Biomass Page 1

Biomass Page 2

Water Tube Boiler

Heat Recovery Boiler

GETABEC-VYNCKE

Biomass Boiler

GETABEC-VYNCKEIn collaboration with our partner company VYNCKE, Belgium special design for Biomass such as rice husk, waste wood, coal etc. As one of our policies to offer the customer the highest product quality, GETABEC has cooperated with the company VYNCKE from Belgium to achieve the best quality product in Biomass boiler industry.Capacity from 1,000 up to 100,000 kg/hrGETABEC together with VYNCKE turns theories into reality!With our partner VYNCKE together we will convert biomass and industrial wasteinto clean energy.

Water Tube Boiler

Page 1

Page 2

Water Tube Boiler

GETABEC-Eckrohrkessel

Water Tube Boiler

GETABEC-EckrohrkesselGETABEC ‐ Eckrohrkessel can be operated with a broad range of fuels. Beside traditional fuels such as oil, gas, coal and wood there are special designs where fuels such as industrial waste, municipal waste, paper, biomass and hazardous waste can be utilized. Due to the excellent reaction on quick load variations and the outstanding quick start‐up behaviour, the GETABEC ‐ Eckrohrkessel is the ideal solution for boiler plants operating with heterogeneous fuels.In all other known water tube boiler designs, especially the Bi‐Drum design, the extracted steam is generated somewhere in the system and rises from the bottom of the drum through the water level resulting in fluctuation of the water level along with the risk of a high percentage of “carry over”.For Small CapacitiesCapacity 1 t/h up to 10 t/h but high design pressures of up to 100 bar - Absolute dry and saturated steam. - No carryover of boiler water even during sudden peak loads. - Immune against sudden load rate changes - No contamination of products - Perfect temperature control of distillation columns.For Medium CapacitiesCapacities up to 150 t/h and design pressures up to 100 barThe GETABEC‐Eckrohrkessel is available as steam generator and as hot water generator. - Easy operation and maintenance due to horizontal and compact design. - Easy access to boiler equipment such as burner and fittings as well as to the heating surfaces. - Applicable for all liquid and gaseous fuels. - Dimensions adaptable to limited space on siteFor High CapacitiesUp to 200 t/h and design pressures up to 100 barRange of capacity of GETABEC boilers - Steam rating up to 200 t/h - Steam pressure up to 100 bar - Steam temperature up to 500 °CThe design principle of the GETABEC ‐ Eckrohrkessel can easily be adapted to the fuels and the plant conditions required by the customer.For any application we choose a particular design, which includes various fuels and combustion systems.This particular boiler design takes into account - The compatibility to the fuel requirements. - The coordination with transport conditions. - The optimisation for the space conditions.
Pix 019.jpg

Thermal Oil Heater

Page 1

Page 2

Biomass Boiler

Water Tube Boiler

Heat Recovery Boiler

Thermal Oil Heater

GETABEC

Thermal Oil Heater

THERMAL OIL HEATER from GETABEC is the most effective and most efficient heat transfer equipment. The use of high‐ temperature thermal oil made on mineral oilbasis or synthetically as transfer media up an outlet temperature of 350 °C eliminates problems typical for water‐steam operation. Also, mineral oils are more effective and more efficient in terms of heat transfer capability. Three Pass design with forced circulationRange of capacity of THERMAL OIL HEATER from GETABEC• 0.4 MW to 15.0 MW, max 350°C up to 8 barThe Thermal Oil Heater from GETABEC heats carrier system operates excellently, safely reliably and guaranteed to last for many years.

Quick Steam Generator

Page 1

Page 2

Steam Boiler

GETABEC-SHOJI

Quick Steam Generator

QUICK STEAM GENERATORGETABEC-SHOJI Once Through Boiler is our new range of product. GETABEC-SHOJI supplies individual boilers as well as complete boiler plants with feed water treatment, feed water storage and deaeration, with heat recovery systems and all additional requested equipment for a state-of-the-art. GETABEC-SHOJI is our recommend product for the vertical type of boiler which is suitable for the limited area.The capacity of boiler start from Capacity 100 kgs – up to 3000 kgs Fuel Heavy Oil, Natural Gas and LPG.
Pix 025.jpg

Heat Recovery Boiler

Page 1

Page 2

Steam Boiler

Biomass Boiler

Water Tube Boiler

Thermal Oil Heater

Quick Steam Generator

GETABEC

Heat Recovery

Steam Boiler

HEAT RECOVERY STEAM BOILERThe Waste Heat Recovery Steam Boiler - HRSG from GETABEC is designed according to the principle of the flame tube/smoke tube boiler. The hot flue gas is directed through pipe bundles, where its heat is transferred to the water inside the boiler body. At the front inlet and rear exit flue gas side of the Waste Heat Recovery Boiler, designed flue gas camper with cleaning apertures. All inlet openings are removable, for an optimal cleaning of the smoke tubes. Our Waste Heat Recovery Boiler to minimize radiation losses is fitted with a composite thermal insulation with a zinc alum iron sheet steel jacket.The Waste Heat Recovery Boiler is fixated on a basic frame that spreads the load across a large area of the floor. For the expansion the boilers designed also the gliding and fixed points together with the base frame.Many industrial processes generate large amounts of waste energy thatsimply pass out of plant stacks and into the atmosphere or are otherwiselost. Most industrial waste heat streams are liquid, gaseous, or acombination of the two and have temperatures from slightly above ambient to over 1000 ºC. At stack gas temperature greater than 500 ºC, the heat going up the stack is likely to be the single biggest loss in the process. Above 900 ºC stack losses will consume at least half of the total fuel input to the process. Yet, the energy that is recovered from waste heat streams could displace part or all of the energy input needs for a unit operation within a plant.Therefore, waste heat recovery offers a great opportunity to productively use this energy, reducing overall plant energy, consumption and greenhouse gas emissions.
Pix 041.jpg

Services

GETABEC

Service Team

RANGE OF SERVICEWe provide a whole range of services required for a boiler plant, engineering, installation, erection, commissioning, spare parts and we provide them for all boiler brands such as followings; Boiler repair such as - tube replacement- repair of pressure parts- repair of refractoryBoiler maintenance such as- annual checks- flue gas side and water side cleaning- emergency serviceBoiler up-grading such as - energy saving measures- efficiency improvement- waste heat recovery (Economizer)- fuel conversion- oxygen control- emission control- NOx reductionBalance of plant such as- water treatment plants- feed water tanks and dearators- oil tanks- chimneys- pressure vessels- blow down tanks- steel structures- dust collectorsOur experienced Service Team with qualified engineers and technicians is equipped to meet all needs.
No Frame

Engineering Pix 027.jpg

GETABEC

Engineering

ENGINEERINGOur Objective is to provide the most efficient and cleanest integrated steam solutions to our customers for steam boilers and all balance of plants, to energy recovery systems and NO x - reduction technology.In additional, GETABEC provided conventional islands for Steam Generation Plant and Turnkey for Engineering, Procurement and Construction (EPC).A highly professional approach of employees with experiences from domestic and international projects is a guarantee of customers satisfaction.
